EvoFox Shadow X Pro
Tri-Mode Wireless Gaming Mouse
Updated on
Additional Resources
Web App
Product Manual
Product Overview
What's in the box?
The box contains:
• EvoFox Shadow X Pro Tri-Mode Wireless Gaming Mouse – Black
• USB Type-C Charging Cable
• 2.4GHz Nano USB Receiver
• Quick Start Guide (QSG)
Quick Setup Guide
How do I power ON the mouse?
• Switch the mouse to 2.4GHz Wireless or Bluetooth mode using the mode selector to power it on.
• The mouse powers on automatically when connected using the wired USB Type-C cable.
How do I connect the mouse?
• Wired Mode: Connect the mouse to your device using the USB Type-C cable.
• 2.4GHz Wireless Mode: Insert the nano receiver into a USB port and switch the mouse to 2.4GHz mode.
• Bluetooth Mode: Switch to Bluetooth mode and pair the mouse with your device from Bluetooth settings.
Do I need to install drivers?
• The mouse works without software for basic use.
• To customize DPI settings, RGB lighting, polling rate, button functions, and onboard profiles, installing the dedicated software is required.
How do I reset the mouse?
• Turn the mouse off, wait a few seconds, and power it back on.
• For a complete reset, reconnect the mouse in wired mode and reapply settings using the software.
Troubleshooting
Why is the mouse not responding in wireless mode?
• Ensure the battery is sufficiently charged and the correct connection mode (2.4GHz or Bluetooth) is selected.
• For 2.4GHz mode, confirm that the nano receiver is properly connected to the USB port.
Why are the RGB lights not turning on?
Confirm that RGB lighting is enabled in the software and ensure the battery has sufficient charge.
Why is the mouse not detected by the software?
• Reconnect the mouse in wired mode and relaunch the software.
• Ensure the mouse is powered on and connected directly to the system.
Features and Customization
How can I adjust DPI settings?
• DPI can be adjusted using the software within a range of 200 to 6400 DPI.
• DPI levels are configurable to suit different gaming preferences.
What are the programmable buttons used for?
• The mouse features 6 programmable buttons.
• Buttons can be remapped through the software for customized controls and actions.
How do I control RGB lighting?
• RGB lighting can be customized using the dedicated software.
• Lighting effects can also be turned off to reduce power consumption.
Power Management
What kind of battery does the Shadow X Pro use?
The mouse uses a built-in 400mAh rechargeable battery.
How do I charge the mouse?
• Charge the mouse using the included USB Type-C cable.
• Charging is supported through the Type-C port while connected to a power source.
How do the LED indicators work?
• Battery level LED indicators display four statuses: 100%, 75%, 40%, and below 20%.
• Connection mode LEDs indicate the active mode:
Blue: Bluetooth
Green: 2.4GHz Wireless
Red: Wired
Compatibility
Which platforms are supported?
• The EvoFox Shadow X Pro supports devices compatible with USB and Bluetooth HID standards.
• Advanced customization is available through supported software on compatible systems.
