EvoFox Ronin Wired
Mechanical Gaming Keyboard
Updated on
Additional Resources
Web App
Product Overview
What’s in the box?
Ronin TKL Wired Keyboard
Detachable 1.5m Type-C Cable with EMI Ring
Key Puller
4 Extra Outemu Red Switches
User Manual
Brand Inserts
Does the Ronin TKL support N-key rollover for gaming?
Yes, the keyboard features full N-key rollover, ensuring that every keystroke is registered—even during intense, simultaneous key presses.
What is the polling rate of the Ronin TKL keyboard?
The Ronin TKL supports a 1000Hz polling rate, delivering ultra-fast response times essential for competitive gaming.
Which type of switches do Ronin TKL have?
Yes. The keyboard uses Outemu Red mechanical switches—linear, silent, and responsive—making them ideal for fast-paced gaming sessions.
Quick Setup Guide
How do I power on the keyboard?
Just connect the included Type-C cable to your device. The keyboard turns on automatically—no power button needed.
Is any software required for basic use?
No. The Ronin TKL is plug-and-play for Windows, macOS, and Linux. Software is only needed for advanced customization on Windows.
How do I switch between Windows and macOS modes?
Use the toggle switch on the back of the keyboard to switch OS modes. Media key layouts adapt automatically.
Features and Customization
What kind of switches does the keyboard use?
It comes with pre-installed Outemu Red switches—linear, silent, and dust-proof. All switches are hot-swappable with 5-pin ProMod sockets.
How customizable is the RGB lighting?
Very. There are 21 RGB presets, per-key customization via software, and dedicated shortcuts for brightness, effect speed, and direction.
What other customization features are available?
Programmable macros and profiles (via software)
Audio reactive RGB effects (software)
Screenshot and Copilot keys (Windows Mode)
Remappable keys (Windows software only)
How do I control the lighting without software?
Turn On/Off: Fn + Del
Cycle Effects: Fn + \
Brightness: Fn + ↑/↓
Effect Speed: Fn + + / -
Cycle Colors: Fn + → / ←
What’s the ergonomic benefit of this keyboard?
How do I reset the keyboard to factory settings?
Power Management
How is the keyboard powered?
Via a USB Type-C wired connection. No battery or external power source required.
Can I power it using a laptop USB port?
Yes, but it's not recommended for maximum performance. Use a powered USB hub or desktop port where possible.
Does it have onboard memory?
Yes, the Ronin TKL can store multiple profiles (RGB, macros) directly on the keyboard—no software needed after setup.
Is the included cable special in any way?
Yes, it’s a braided 1.5m Type-C cable with EMI shielding for stable, interference-free performance.
Compatibility
Which platforms does the Ronin TKL support?
Fully compatible with Windows, macOS, and Linux. Software features are available only on Windows.
Does the Copilot button work on all systems?
No. The Copilot key (F4) requires Windows 11 or later and only functions in Windows Mode.
Will all media keys work on macOS?
Most will. However, certain functions (like Copilot and Screenshot) are exclusive to Windows Mode.
Troubleshooting
My keyboard isn’t responding. What should I do?
Check USB connection and try another port.
Restart your system.
Verify OS mode toggle.
Test on another device to rule out hardware issues.
Some keys aren’t registering.
Use the key puller to remove the cap and check for debris.
Reseat or replace the switch with the included extras.
Try resetting the keyboard (Fn + ESC for 5 sec).
RGB lighting isn't working.
Toggle it on with Fn + Del
Adjust brightness using Fn + ↑/↓
Replug the keyboard to reset lighting
Multimedia keys aren’t functioning.
Ensure the OS toggle matches your system
Some apps may not support certain media controls
Hot-swappable switch not working.
Ensure switch pins are straight and fully inserted
Use one of the included spare switches to test
Volume knob or Copilot key doesn’t work.
These work only in Windows Mode
Update to Windows 11+ for Copilot functionality
Experiencing EMI or connectivity issues.
Use the provided EMI-shielded cable
Try a USB 2.0 port to reduce interference
Keyboard not detected by software?
Ensure you’re using Windows OS
Download and install the latest software version from the EvoFox website
